Integra Integrated

Integra Integrated

This is a musical and visual expression of our Integrated amplifier range, plundering its stablemate for its internal building blocks.

Offering an impressive sound quality that obvious from the first few moments, suddenly you escape into a soundstage you didn't expect to find in your music collection.

"INTEGRA played any music I fed it with near perfection"
- Janine Elliot

Key Features

  • ALPS Volume Control
  • Pellar Integated Phono
  • Headphone Amplifier

SUper Powers

Powering your music is a huge transformer, electrical reservoir and the mono amplifiers from our SIGSUM. Avoiding unwanted circuitry noise which tarnishes the sound, we have harnessed a silky-smooth ALPS volume control and bespoke capacitors from our Reference models offering a warmth that makes listening an endless pleasure.

“If you want to get blown away – this is an amplifier worth hearing”
- Noel Keywood

Winning Design

Winning Design

From inception a multitude of Industry accolades have been bestowed on this musical amplifier, connecting you vividly to the performance, either through the built in Pellar phonostage or its numerous line inputs. Listening with loudspeakers opens up a glorious soundstage and for those moments of solitude you have the exceptional headphone output. A winning design that is also winning hearts and awards.

"Notes start and stop precisely, expressing rhythmic flow"
- John Pickford

Related Products

What's inside

Cascading directly from the SIGSUM integrated amplifier, the specifications are no less impressive. Appealing to its customers and the growth in vinyl reproduction the INTEGRA includes the award winning Pellar Phonostage, fully compatible with all pick-up cartridges. Using our bespoke polypropylene capacitors in critical signal paths and the final signal running through the exceptional ALPS volume control. The excellent headphone amplifier is perfect for those wanting escapist listening sessions.

Employing a huge 750VA mains transformer and 88,000uF of electrical storage capacity there is no holding back the impressive dynamics you hear in real music.

Crafted from heavy gauge steel to screen sensitive components from external assault, every detail is done with finesse, from the solid aluminium front panel with our distinctive designed controls to the beautiful cover with logo hole patterning and INTEGRA name proudly being displayed. From the moment you open the packaging to lifting the amplifier, you will feel precision quality and craftsmanship.

Specifications

POWER OUTPUT:

90W 8Ω

HARMONIC DISTORTION:

0.003% (80% POWER 8Ω 1KHz)

LOUDSPEAKER IMPEDANC:

4-16Ω

PHONO INPUTS:

2x RCA

GAIN:

48dB – 60dB – 70dB

INPUT RESISTANCE:

47K - CUSTOM (500Ω LOADING PLUGS SUPPLIED)

INPUT CAPACITANCE:

100pF

LINE INPUTS:

4x RCA LINE INPUTS

OUTPUTS:

4x GOLD PLATED HIGH CURRENT

LINE LEVEL OUTPUT:

2x RCA

HEADPHONE OUTPUT:

10 V RMS

HEADPHONE RANGE:

20 — 600Ω

INPUT VOLTAGE:

115V OR 230V AC

DIMENSIONS:

470 x 495 x 155mm (WXDXH)

NET WEIGHT:

22.9KG (50Lb)
